Thermostatic baths
for immersion resistance tests
The thermostatic baths, BT or BTF series, are used for testing immersion resistance, heat treatment of samples, high and low-temperature behaviour, cleaning and curing of materials, among others. It is possible to manufacture the equipment with a cooling unit.
Its temperature range is from +5°C to +95°C, the volume of the equipment can be 210, 336, 480, 756 and 1040 Litres, for other sizes please consult us. Thermostatic baths can be used in all industrial sectors.
At Ineltec, we design and manufacture customised equipment according to customer specifications, modifying or extending the standard features.
DIN, ISO, ASTM, EN, MIL, VDA, AENOR, STD, IEC, ISO 2812.2, etc.
Exterior: Made of white lacquered aluminium sheeting.
- Cabinet base: 4 anti-vibration feet, height adjustable.
Interior: Made of AISI-304 stainless steel.
- Access holes: 2 Wall bushings Ø 30mm (others on request).
Insulation: by means of fibreglass panels.
- Density: 41kg/m3
- Coefficient of thermal transmission: 0.163 Kcal/m² hºC
Dimensiones: (HxWxL)
| Volume | 210 L | 336 L | 480 L | 756 L | 1040 L |
| Inside dimensions | 700 x 600 x 500 | 700 x 800 x 600 | 800 x 1000 x 600 | 900 x1200 x 700 | 1000 x 1300 x 800 |
| Outside dimensions | 1100 x 1200 x 700 | 1100 x 1400 x 800 | 1200 x 1600 x 800 | 1300 x 1800 x 900 | 1400 x 1900 x 1000 |
