Modular climatic or temperature chamber
simulate heat, cold and/or humidity environmental conditions over large samples
The Modular Chambers are designed for testing large samples and simulate the environmental conditions of cold, heat and/or humidity. being able to accelerate the life cycle of products and evaluate the resistance of materials in order to know their quality.
Modular chambers are manufactured with removable panels, making their construction fully customizable and adaptable to volume requirements (from 2000 litres) and ranges of work required by the client. We analyze each project in a particular and detailed way, making them unique.
Modular climatic or thermal chambers are used in all industrial sectors, as they comply with testing standards for any product or material.
There is the possibility to install solar radiation, UV Ultraviolet, Infrared, as well as other options (snow, rain, wind, etc.) to test the tightness of the samples and it is adaptable to vibration systems, etc.
DIN, ISO, ASTM, EN, MIL, VDA, AENOR, STD, IEC, ICH, FDA.
Modular structure assembled with thermo-injected polyurethane sandwich panels, highly resistant and removable, allowing for future relocation or expansion.
Exterior: Made with injected polyurethane sandwich panels.
- Access door: Hermetically sealed isothermal pivot door, key lock and emergency opening from the inside.
- Sight glass: Multicrystal tempered, 10 vacuum-sealed glass panes, size depending on chamber volume.
Interior: Inner side of the panels in galvanised steel sheet, white lacquered
- Interior lighting: Fluorescent
- Access holes: 1 wall bushing Ø 100 mm (others on request).
- Shelves: Shelving modules, with height-adjustable and easily removable perforated trays. Allow air circulation between samples (on request).
Insulation:
- Density 41-42 Kg/m³
- Thermal conductivity Coefficient 0,0136 Kcal/m. hºC
- Coefficient of thermal transmission: 0.163 Kcal/m² hºC cables, adjustable in height. Max. weight 50 kg (others on request).
The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.
- Manual or automatic programming
- Possibility of programming date and time of the test
- It allows recording notes during the tests
- Different access levels
- Maximum 11 operators
- Display and recording of tests in a graphical or tabular table
- Export to excel or similar
- Setting of minimum and maximum alarms for temperature and humidity for each section
- It includes recording screen, incidences and maintenance.
