according with standards ICH and FDA

Stability climatic or thermal stability chambers, INSTAB model, series are designed to store or condition products under stable temperature and humidity conditions in accordance with ICH and FDA regulations.

This type of stability chamber is available in four volumes, 300,600, 1300 and 1800 L is mainly used in the pharmaceutical, biotechnological, dermo-aesthetic and veterinary sectors,

At Ineltec, we adapt to the needs of our clients by offering modular stability chambers with the possibility of installing solar radiation (photostability).

Characteristics
300, 600 and 1800 L (Others under request)
From +5 °C to +60 °C (climatic and thermal)
They can be thermal, climatic or photostable
Standards

ICH, FDA, ISO 10977

. . .
  • Temperature ranges:
    • From 5ºC to +60ªC (climatic)
    • From 0ºC to + 30 ºC (conservation)
    • From -30ºc to + 30 ºC (freezing )
  • Volume: 300,600,1200,1800 L It is possible to create a chamber with different compartments of 600 litres.
  • H.R: 10%-98%

In all the volumes

Exterior: Made of AISI-304 stainless steel.

  • Access door: Flexible silicone gasket, size according to chamber volume
  • Mobility: 04  swivel castors with 2 braking devices or 4 height adjustable legs

Interior: Made of AISI – 304 stainless steel

  • Access holes: 1 side wall bushing Ø 50mm (others on request)
  • Accessories: 4 sample-holding trays, adjustable in height (others on request).

Insulation

  1.  Density: 41 Kg/m3
  2. Coefficient of thermal conductivity: 0,0136 Kcal/m.h.ºC
  3. Coefficient of thermal transmission: 0.163Kcal /m2 hº C
  4. Completely waterproof and resistant to corrosive attack by acids and alkalis

Dimensions: (HxWxL)

Volume 300 L 600 L 1300 L 1800 L
Inside dimension 700 x 600 x 700 1470 x 582 x 687 1470 x 1282 x 687 1470 x 1800 x 650
Outside dimension 1200 x 700 x 1175 2075 x 700 x 1175 2075 x 1400 x 1175 2075 x 2100 x 1175



The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.

  1. Manual or automatic programming
  2. Possibility of programming date and time of the test
  3. It allows recording notes during the tests
  4. Different access levels
  5. Maximum 11 operators
  6. Display and recording of tests in a graphical or tabular table
  7. Export to excel or similar
  8. Setting of minimum and maximum alarms for temperature and humidity for each section
  9. It includes recording screen, incidences and maintenance.
