to check the damage caused to the sample by the different frequencies of the sun's rays.

The simulation of sunlight is to check the damage caused by different frequencies of solar rays. The system allows the installation of different filters to work with the desired wavelength, ultraviolet, visible light, infrared or both.

The reference application of the equipment is the accelerated ageing of the sample, under the effects of radiation combined with other environmental phenomena. Its temperature range is from -50°C to +85°C, other conditions can be consulted.

The climatic chamber with radiation can be used in any industrial sector and it can also be combined with other tests, such as rain tightness.

Characteristics
From -50ºC to + 85ºC
10-98%
Adjustable power from 0-1250W/m3
Standards

DIN 75220, ISO 4892-2, IEC 60068-2-5, EN 60068-2-5, CIE 20, ISO 11341, MIL –STD-810E mét.505.3

. . . .

Exterior: It is made of a white lacquered aluminium sheet.

  • Access door: Flexible double silicone gasket, sized according to chamber volume.
  • Viewing window: Tempered multi-crystal, 6 argon-sealed glass panels, size according to chamber volume.
  • Mobility: 4 swivel wheels with 2 braking devices or 4 height-adjustable legs.

Interior: It is made of AISI-304 stainless steel.

  • Interior lighting: LED strip.
  • Access Holes 1 side wall hole Ø 50mm (others on request)
  • Accessories: 2 sample-holding trays made of perforated stainless steel plate, adjustable in height. Max weight 50 Kg ( others on request)

Insulation

  • Density 41 kg/m3
  • Coefficient of thermal conductivity: 0,0136 Kcal/m. hºC
  • Coefficient of thermal transmission
  • Completely waterproof and resistant to corrosive attack by acids and alkalis

The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.

  1. Manual or automatic programming
  2. Possibility of programming date and time of the test
  3. It allows recording notes during the tests
  4. Different access levels
  5. Maximum 11 operators
  6. Display and recording of tests in a graphical or tabular table
  7. Export to Excel or similar
  8. The setting of minimum and maximum alarms for temperature and humidity for each section
  9. It includes recording screen, incidences and maintenance.
