They are designed according to customer specifications to perform tests where different conditions are combined simultaneously.

Thermal or climatic chambers can be combined with different tests such as vibration, pulsating pressure, solar or ultraviolet radiation, mechanical movement, etc. They are designed to be adapted to a test bench.

This special equipment is customized for the client in order to meet their needs. They are used in all industrial sectors, as they comply with testing standards for any product or material.

Characteristics
From 150 L to 2000 L (other on request)
From -70 ºC to + 180 ºC
Standards

According to customer specifications and international standards

Documents
Special equipment
. . . .
  •      Temperature range: min -70ºC to max +150ºC
  • Humidity range: 10-98 % according to the psychometric diagram*
  • Volume: from 150L to 2000L  (others on request )
  • Gradients (according to IEC-60068-3-5 standard): max. average values without load  3-5-10-15-20 ºC/min

Examples of equipment that we have designed and manufactured according to customer requirements:

  • Chamber with vibration and pulsating pressure
  • Chamber with an arm robot
  • Radiation and rain tightness chamber
  • Liquid and air thermal shock chamber
  • Chamber attached to a testing bench of traction and compression
  • Chamber to adapt a vibrator
  • Chamber adapted to a mechanical movement





Exterior: It is made of white lacquered aluminium sheet.

  • Access door: Flexible silicone double seal,  size according to chamber volume
  • Viewing window: Tempered multi-crystal 500x500mm, 06 vacuum sealed glass panels
  • Mobility: 4 swivel wheels with 2 braking devices or 4 legs adjustable in height.

Interior: It is made of AISI-304 stainless steel.

  • Interior lighting: Fluorescent with interior projection.
  • Access Holes 1 side wall hole Ø 50mm (others on request)
  • Accessories: 2 sample-holding trays made of perforated stainless steel plate, adjustable in height. Max weight 50 Kg (others on request)

 Insulation:

  • Density 41 kg/m3
  • Coefficient of thermal conductivity: 0,0136 Kcal/m. hºC
  • Coefficient of thermal transmission
  • Completely waterproof and resistant to corrosive attack by acids and alkalis

The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.

  1. Manual or automatic programming
  2. Possibility of programming date and time of the test
  3. It allows recording notes during the tests
  4. Different access levels
  5. Maximum 11 operators
  6. Display and recording of tests in a graphical or tabular table
  7. Export to Excel or similar
  8. The setting of minimum and maximum alarms for temperature and humidity for each section
  9. It includes recording screens, incidences and maintenance.
