Desktop climatic chambers
ideal for simulating hot, cold and humid conditions for small samples, or for laboratories with limited space.
Ineltec's desktop climatic chambers, model INSMP, INSMR, INSMCP and INSMCR, simulate the environmental conditions of hot and cold and they can add humidity conditions.
The temperature range of Standard models goes from -10ºC to + 150 ºC.
This type of chamber is used in all industrial sectors because they comply with the standard for environmental testing of any product or material.
At Ineltec, we design and manufacture customized equipment according to customer specifications, modifying or extending the standard features. We can add wall access holes, gloves or combine different tests.
DIN, ISO, ASTM, UNE, MIL, VDA, AENOR, STD, IEC, ICH, FDA, IEC 60068
INSMP or INSMR (thermal) / INSMCP or INSMCR (climatic) model
| Volumes | Temperature ranges | Relative humidity | Gradient | Stability (temp.) | Resolution (temp.) | Accuracy (temps.) |
| 100 l | -10ºC to +150ºC | 10-98% |
Ref. 3ºC/min Cal. 3ºC/min |
±0.3ºC max. | 0.1 ºC | ±0.5ºC max. |
| 150 l | -10ºC to +150ºC | 10-98% | ±0.3ºC max. | 0.1 ºC | ±0.5ºC max. |
Exterior: It is made of white lacquered aluminium sheet.
- Access door: Flexible double silicone gasket, sized according to chamber volume.
- Viewing window: 300x300mm Multicrystal tempered, 4 argon-sealed glass panes.
- Mobility: 4 swivel wheels with 2 braking devices or 4 height-adjustable legs-
Interior: It is made of AISI-304 stainless steel.
- Interior lighting: LED strip with interior projection.
- Access Holes 1 side wall hole Ø 50mm (others on request)
- Accessories: 2 sample-holding trays made of perforated stainless steel plate, adjustable in height. Max weight 50 Kg ( others on request)
Insulation
- Density 41 kg/m3
- Coefficient of thermal conductivity: 0,0136 Kcal/m. hºC
- Coefficient of thermal transmission
- Completely waterproof and resistant to corrosive attack by acids and alkalis
Dimensions: (HxWxL)
| Volume | 100 L | 150 L |
| Inside Dimensions | 600 x 550 x 310 | 600 x 550 x 460 |
| Outside Dimensions | 1446,5 x 750 x 1049 | 1446,5 x 750 x 1152 |
The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.
- Manual or automatic programming
- Possibility of programming date and time of the test
- It allows recording notes during the tests
- Different access levels
- Maximum 11 operators
- Display and recording of tests in a graphical or tabular table
- Export to excel or similar
- Setting of minimum and maximum alarms for temperature and humidity for each section
- It includes recording screen, incidences and maintenance
