Hazard chambers (battery tests)
Special climatic chambers for lithium-ion battery testing
Hazard chambers are equipped with the necessary accessory to assure Hazard safety levels between levels 1 and 7. It is used for tests on cells, modules, lithium batteries, etc.
The maximum temperature ranges in standard models are -70ºC being able to reach up to +180ºC, the volume of the equipment can be from 150 litres to 2000 litres, for other sizes please consult us.
The chambers are mainly used in the automotive, electronics or technology sectors and in testing laboratories.
At Ineltec, we design and manufacture customized equipment according to customer specifications, modifying or extending standard features. Learn more about the levels of risk that different tests may have in this article.
UNE EN 60068 2 40:2000
UNE EN 60068 2 41:2000
Hazard chambers have the same technical characteristics as climatic chambers, but to assure safety during the test we add the following resources according to the required Hazard level:
Exterior: It is made of white lacquered aluminium sheeting.
- Access door: Flexible silicone double seal, size according to chamber volume
- Viewing window: Tempered multi-crystal 500x500mm, 06 vacuum sealed glass panels
- Mobility: 4 swivel wheels with 2 braking devices or 4 legs adjustable in height.
Interior: It is made of AISI-304 stainless steel.
- Interior lighting: Fluorescent with interior projection.
- Access Holes 1 side wall hole Ø 50mm (others on request)
- Accessories: 2 sample-holding trays made of perforated stainless steel plate, adjustable in height. Max weight 50 Kg (others on request)
Insulation
- Density 41 kg/m3
- Coefficient of thermal conductivity: 0,0136 Kcal/m. hºC
- Coefficient of thermal transmission
- Completely waterproof and resistant to corrosive attack by acids and alkalis
The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.
- Manual or automatic programming
- Possibility of programming date and time of the test
- It allows recording notes during the tests
- Different access levels
- Maximum 11 operators
- Display and recording of tests in a graphical or tabular table
- Export to Excel or similar
- The setting of minimum and maximum alarms for temperature and humidity for each section
- It includes recording screens, incidences and maintenance.
