causes the ignition of the gases released and the propagation of combustion

The cone calorimeter (ISO 5660-1) is intended to quantify the amount of heat released by a sample exposed to controlled levels of radiation. The time to ignition of the sample is also measured

The characteristics obtained from the sample after the test are as follows:

  1. Speed of heat release
  2. Heat release rate per unit area (kW.m2)
  3. speed of weight loss ( kW.S)
  4. Time for ignition of the test tube
  5. Smoke density
  6. Weight of soot falling from the test tube (kg/Kg.)
  7. Effective heat of combustion
  8. The toxicity level of emitted gases

 ISO 5660 – 1-2-3, ASTM-1354


The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.

  1. Manual or automatic programming
  2. Possibility of programming date and time of the test
  3. It allows recording notes during the tests
  4. Different access levels
  5. Maximum 11 operators
  6. Display and recording of tests in a graphical or tabular table
  7. Export to excel or similar
  8. Setting of minimum and maximum alarms for temperature and humidity for each section
  9. It includes recording screen, incidences and maintenance.
