in order to be able to determine the fire behaviour, analysing flame spread and measuring surface flammability

The radiant panel is designed to be able to determine fire behaviour, analyse flame spread and measure surface flammability in floor coverings (EN ISO 9239-1), building products (ASTM E162) and cellular plastics (ASTM D3675), by using a radiant heat panel.

The test result is an index that is determined from the flame spread and heat evolution factors. This index is required in several specifications, especially for the public transport industry (buses and trains).

The equipment consists of a test area in which the sample is placed. It also includes a radiant panel, a sample holder, a pilot burner, a fume extraction system and a control station associated with a measurement system.

EN ISO 9239-1, ASTM E 648,  ASTM E 970,  NFPA 253, ASTM E 162, ASTM D 3675.


EN ISO 9239-1, ASTM E 648,  ASTM E 970,  NFPA 253, ASTM E 162, ASTM D 3675


The touch screen PC has the PROCAM-WIN installed. It is easy and intuitive software which performs programming tasks, acquisition, records, control and analysis of the results.

  1. Manual or automatic programming
  2. Possibility of programming date and time of the test
  3. It allows recording notes during the tests
  4. Different access levels
  5. Maximum 11 operators
  6. Display and recording of tests in a graphical or tabular table
  7. Export to excel or similar
  8. Setting of minimum and maximum alarms for temperature and humidity for each section
  9. It includes recording screen, incidences and maintenance.
